GIGABYTE Z690I AORUS ULTRA Motherboard
₪560.00
GIGABYTE Z690I AORUS ULTRA Motherboard
Specification
| ModelGIGABYTE Z690I AORUS ULTRA | Warranty3 Years | DDR5 Slots2 |
| Memory TypeDDR5 | PackagingRetail - box | PCI-E x16 Slot1 |
| USB PortsUSB 2.0 \ USB 3.2 \ USB Type-C | USB Type-C Port2 | Wireless Network CardYes |
Description
The GIGABYTE Z690I AORUS ULTRA motherboard offers high performance and technological innovation for Mini ITX systems. Featuring the Intel Z690 chipset and a 1700 CPU socket, the board supports DDR5 memory and provides two expansion slots. Connectivity options include Wi-Fi 6/6E, 2.5 Gigabit LAN, and Bluetooth 5.2, ensuring fast and stable connectivity. The board is equipped with two SATA3 connectors and two M.2 PCIe connectors, supports RAID 0 and 1 configurations, and offers a variety of USB connections, including USB 3.2 and USB Type-C. Graphics connectivity is enabled via HDMI and DisplayPort, and an integrated audio card with two ports provides high sound quality. With a 3-year warranty, the board is an ideal solution for building compact and high-performance computers.
Specifications GIGABYTE Z690I AORUS ULTRA Motherboard
General
| Model | GIGABYTE Z690I AORUS ULTRA |
|---|---|
| Warranty | 3 Years |
Additional
| DDR5 Slots | 2 |
|---|---|
| Memory Type | DDR5 |
| Packaging | Retail - box |
| PCI-E x16 Slot | 1 |
| USB Ports | USB 2.0 \ USB 3.2 \ USB Type-C |
| USB Type-C Port | 2 |
| Wireless Network Card | Yes |
Chipset
| Chipset | Intel Z690 |
|---|
Connections
| USB 2.0 | 6 |
|---|---|
| USB 3.2 | 7 |
Expansion
| Expansion Slots | PCIe 4.0 x16 |
|---|
Graphics
| Graphics Interface | HDMI \ DisplayPort |
|---|
Network
| Communication Interfaces | Wi-Fi 6/6E (802.11ax) \ LAN 2.5 Gigabit \ Bluetooth 5.2 |
|---|
Structure
| Board Configuration | Mini ITX |
|---|
Audio
| Integrated Sound Card | 2 ports |
|---|
Processor
| Processor Socket | 1700 |
|---|
Storage
| M.2 PCIe Connectors | 2 |
|---|---|
| RAID | 0,1 |
| SATA3 Connectors | 2 |
| Storage Interface | SATA3 \ M.2 PCIe |
