| ChipsetH55 | ManufacturerMSI | New / UsedNew |
| RAM TypeDDR3 | Secondary CategoryIntel Motherboard | Sizemicro-ATX |
| Socket1156 | WarrantyOne Year Warranty |
CPU
• Supports Intel® i3 / i5 / i7 based processors in LGA1156 package.
Chipset
• Intel® H55 Chipset
– Supports QPI up to 6.4GT/s
– Hi-Speed USB (USB2.0) controller, 480Mb/sec.
– 6 SATAII ports with transfer rate up to 3Gb/s.
– PCI Master v2.3, I/O APIC.
– ACPI 2.0 compliant.
Main Memory
• Supports four unbuffered DIMM of 1.5 Volt DDR3 1066/1333/1600*/2000*/2133* (OC) DRAM, 16GB Max
– Supports 1Gb/ 2Gb/ 4Gb DRAM size
– Supports Dual channel mode
Slots
• 1 PCI Express gen2 x16 slot
• 2 PCI Express gen2 x1 slots
• 1 PCI slots, support 3.3V/ 5V PCI bus Interface
On-Board IDE/SATA
• One Ultra DMA 133/150 IDE controller integrated in Marvell® 88SE9128B1.
– Supports PIO, Bus Master operation modes.
– Can connect up to two Ultra ATA drives.
• SATAII controller integrated in Intel H55 chipset
– Up to 3Gb/s transfer speed.
– Supports six SATAII ports by H55
• SATAIII controller integrated in Marvell® 88SE9128B1 chipset
– Up to 6Gb/s transfer speed.
– Supports two SATAIII ports (SATA7~8) by 88SE9128B1
– SATA7~8 ports support RAID 0/ 1 mode
USB 3.0
• 2 USB 3.0 ports by NEC® uPD720200F1
Audio
• Chipset integrated by Realtek® ALC892
– Flexible 8-channel audio with jack sensing
– Compliant with Azalia 1.0 Spec
– Meet Microsoft Vista Premium spec
LAN
• Supports one PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111E.
Internal I/O Connectors
– ATX 24-Pin power connector
– 4-pin ATX 12V power connector
– CPU x 1 / System x 2 FAN connectors
– CD-in connector
– Front panel audio connector
– Front panel connector
– 1 x chasis intrusion connector
– 3 x USB 2.0 connectors
– 6 x Serial ATAII connectors
– 2 x Serial ATAIII connectors
– 1 x ATA150 connector
– 1 x OC Switch
– 1 x Clear CMOS jumper
– 1 x SPDIF-out connector
– 1 x TPM module connector
– 2 x Serial port connectors
– 1 x Parallel port connector
| Chipset | H55 |
|---|---|
| Manufacturer | MSI |
| New / Used | New |
| RAM Type | DDR3 |
| Secondary Category | Intel Motherboard |
| Size | micro-ATX |
| Socket | 1156 |
| Warranty | One Year Warranty |
